Search Results (144)
Technical Bulletin: Mazda 2.2L Two Stage Installation Kit Options
This Technical Bulletin covers new versions of the installation kits that have been introduced for the Mazda 2.2L two stage.
What Does An External Wastegate Do?
Garrett Vent | External Wastegates regulate turbocharger shaft speed by venting exhaust gas around the turbine stage of the turbocharger to the exhaust.
New Product! External Wastegates
Garrett Motion, a Global Differentiated Technology Leader, releases an external wastegate product line to complement its turbocharger and intercooler portfolio.
Whitepaper – Garrett Intrusion Detection Systems
In this whitepaper, Garrett presents its Intrusion Detection System (IDS) software, an adaptable hardware-independent solution providing highly accurate anomalies detection for CAN and Ethernet networks combined with advanced analytics cloud-based tools allowing OEMs to monitor entire fleets.
Webinar – Stay Ahead of Hackers with Garrett’s Adaptable, Multi-Network Vehicle Intrusion Detection System
In this webinar, Garrett presents its best-in-class Intrusion Detection System (IDS) software, integrating multi-network and application processor detection-isolation-report-response algorithms. Garrett IDS is an adaptable hardware-independent solution providing highly accurate anomalies detection for CAN and Ethernet networks combined with advanced analytics cloud-based tools allowing OEMs to monitor entire fleets.
11 Point Turbo System Checklist
The turbo system in your car should be monitored to insure that every aspect is functioning properly to give you trouble-free performance.
Turbocharger Oil Leakage – Troubleshooting
A properly installed turbo should NOT leak oil. There are, however, instances where oil leaks occur. Here are the most common causes, depending on the location of the leak.
How To Size Charge Air Tubing
The duct diameter should be sized with the capability to flow approximately 200 - 300 ft/sec. Selecting a flow diameter less than the calculated value results in the flow pressure dropping due to the restricted flow area.
Turbocharger Water Cooling – Thermal Siphoning
Water cooling is a key design feature for improved durability and we recommend that if your turbo has an allowance for water cooling, hook up the water lines. Water cooling eliminates the destructive occurrence of oil coking by utilizing the Thermal Siphon Effect to reduce the Peak Heat Soak Back Temperature on the turbine side piston after shut-down. In order to get the greatest benefit from your water-cooling system, avoid undulations in the water lines to maximize the Thermal Siphon Effect.
Turbocharger Oil Drainage
In general, the larger the oil drain, the better. However, a -10AN is typically sufficient for proper oil drainage
Turbo Oil Restrictors & Oil Supply
An oil restrictor is recommended for optimal performance with ball bearing turbochargers. Oil pressure of 40 – 45 psi at maximum engine speed is recommended to prevent damage to the turbocharger’s internals. In order to achieve this pressure, a restrictor with a 0.040” orifice will normally suffice, but you should always verify the oil pressure entering the turbo after the restrictor to ensure the components function properly. Recommended oil feed is -3AN or -4AN line or hose/tubing with a similar ID. As always, use an oil filter that meets or exceeds the OEM specifications.
