GTX3584RS Turbocharger

Horsepower: 550 - 1000

Displacement: 2.0L - 5.5L

Features

  • GEN 2 AERODYNAMICS FEATURE INCREASED HORSEPOWER RANGE
  • ”RS” DESIGNED, HIGH HORSEPOWER TURBINE WHEEL
  • 67mm TURBOCHARGER COMPRESSOR OPTION
  • COMPACT DESIGN FOR TIGHT INSTALLATIONS
  • NEW FULLY-MACHINED SPEED SENSOR PORT.
  • COMP OUTLET AVAILABLE IN V-BAND & HOSE CONNECTION

WARNING: Maximum allowable turbocharger speed is 130krpm. The use of this product above max turbocharger speed is at the owner’s risk, and can result in damage and premature failure. To protect the turbocharger from overspeed when operating, a speed sensor can be installed into the compressor housing to monitor shaft speed. Sensors sold separately. (click here for details)

Performance results of this product are highly dependent upon your vehicle’s modifications and tuning/calibration. The horsepower numbers represented above are calculated based strictly on choke flow of the compressor map (total turbo capability), which represents the potential flywheel horsepower.

Learn More About Turbos

GTX3584RS 67mm

Reference Data

The latest Garrett technologies featuring many advanced features.


GTX3584RS Compressor Turbine
Inducer Exducer Trim A/R Inducer Exducer Trim
HP: 550-1000              Disp: 2.0L-5.5L 67mm 84mm 64 0.72 68mm 62mm 84
Supercore Assembly Kit Turbine Kit A/R Inlet Outlet Wastegate Divided
846098-5001S 856804-5001S 740902-0067 0.83 V-Band V-Band Free Float N
Hose bead comp outlet 856804-5002S 740902-0066 1.01 V-Band V-Band Free Float N
856804-5003S 740902-0052 1.21 V-Band V-Band Free Float N
846098-5002S 856804-5004S 740902-0067 0.83 V-Band V-Band Free Float N
V-band comp outlet 856804-5005S 740902-0066 1.01 V-Band V-Band Free Float N
856804-5006S 740902-0052 1.21 V-Band V-Band Free Float N

GTX3584RS 67mm

Download Section

The latest Garrett technologies featuring many advanced features.

File Name Link View
Configuration Guide Download View
File Name Link View
Compressor Map Download View
Exhaust Flow Chart Download View
Product Photo Download View
Flange Diagram Download View
Speed Sensor Kit Installation Instruction Download View

GTX3584RS 67mm

Compressor Map & Exhaust Flow Chart

The latest Garrett technologies featuring many advanced features.

Compressor Map

Exhaust Flow Chart

Garrett GTX3584RS. The only mid-frame turbocharger on the market capable of producing 550-1000 horsepower for 2.0L – 5.5L engines. The GTX3584RS is a clean-sheet product with many new features geared towards enthusiasts.

A brand new high horsepower turbine wheel flows exhaust gasses at a higher, more efficient rate than other GT and GTX turbine wheel designs. The new turbine wheel design allows for higher exhaust gas flow which increases aerodynamic efficiency compared to the previous design. New hi-flowing, stainless steel turbine housings help decrease backpressure and range in size from 0.83, 1.01, and 1.21 A/R. These compact turbine housings are unique only to the GTX3584RS meaning they are not interchangeable with other GT/GTX35 products because of the new turbine wheel.

A new ten-blade GTX Gen II compressor wheel designed using proprietary Garrett Motion computer simulation software gives the GTX3584RS the ability to create more air mass flow, allowing the enthusiast a wider range of power output when tuning the vehicle. A larger, 0.72 A/R compressor housing allows the compressed air flow to circulate into the engine more efficiently than other mid-frame turbochargers. The 8mm dual ceramic ball bearing cartridge provides optimal turbo response and reliability through its reduction in shaft motion. V-band and hose connection compressor outlet options are now offered so be careful to select the appropriate part number when ordering.

GTX3584RS turbochargers feature a fully-machined compressor inlet, fully-machined compressor outlet, and fully-machined ported shroud.

The new compressor housings are equipped with a fully machined speed sensor port that accepts the Garrett Motion speed sensor (Sold separately). This feature allows tuners to understand existing operating conditions, which is important when fine tuning a turbocharger to its most efficient operating conditions. The speed sensor port comes plugged from the factory and can be removed using a 5mm allen key when ready to install a speed sensor kit.

GTX3584RS turbochargers are only offered through Garrett Motion authorized distribution centers.

About Garrett GTX Series Turbochargers

Garrett GTX Series turbochargers are designed specifically for the hard-core enthusiast who wants optimal performance. The forged fully-machined billet aluminum compressor wheels feature next generation aerodynamics that provide a larger horsepower range and maximize boost response.

Ported shroud compressor housings increase surge resistance and provide reliable, continuous power throughout the power band. A dual ceramic ball bearing cartridge prolongs the lifespan and improves shaft balance. The water cooled CHRA keeps housing temperatures to a minimum. The turbine wheel is constructed from Inconel, a Super Alloy that maintains strength during prolonged exposure to high exhaust gas temperatures.

Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. GTX Series turbochargers are used by today’s top motorsports teams and are ready to boost you to the podium or wherever your destination may be.
