GTX3071R GEN II Turbocharger

Horsepower: 340 - 650

Displacement: 1.8L - 3.0L

Features

  • GEN II AERODYNAMICS FEATURE INCREASED HORSEPOWER RANGE
  • NEW FULLY MACHINED SPEED SENSOR PORT.
  • SOLD AS ASSEMBLY KITS (SUPER CORE + TURBINE HSG)
  • NEW REVERSE ROTATION CONFIGURATIONS AVAILABLE

Learn More About Other Racer Vehicle Setups

Each of these contain a detailed vehicle write up and dyno graphs.

GTX3071R GEN II

Reference Data

The latest Garrett technologies featuring many advanced features.

Turbocharger Part Number Chart
CompressorTurbine
Super Core Reference DataInducerExducerTrimA/RInducerExducerTrim
GTX3071R Standard Rotation54mm71mm580.6060mm55mm84
 GTX3071R Reverse Rotation54mm71mm580.6060mm55mm84
Notes:Assembly Kit PNSuper Core PNTurbine Kit PNA/RInletOutletWastegateDivided
Assembly Kit PN Includes Super Core and Turbine Kit856801-5006S851154-5002S740902-00090.63T3V-BandFree FloatN
856801-5005S851154-5002S740902-00080.82T3V-BandFree FloatN
856801-5004S851154-5002S740902-00071.06T3V-BandFree FloatN
856801-5018S851154-5002S740902-00360.61V-BandV-BandFree FloatN
856801-5017S851154-5002S740902-00350.83V-BandV-BandFree FloatN
856801-5016S851154-5002S740902-00341.01V-BandV-BandFree FloatN
Wastegated Turbine Assembly PN does not include bolts, clamps, or actuator856801-5021S851154-5002S771300-00060.63T35 boltWastegatedN
856801-5020S851154-5002S771300-00050.82T35 boltWastegatedN
856801-5019S851154-5002S771300-00041.06T35 boltWastegatedN
Reverse Rotation ConfigurationAssembly Kit PNSuper Core PNTurbine Asbly PNA/RInletOutletWastegateDivided
856802-5001S844621-5003S740902-00530.61V-BandV-BandFree FloatN
856802-5002S844621-5003S740902-00540.83V-BandV-BandFree FloatN
856802-5003S844621-5003S740902-00551.01V-BandV-BandFree FloatN

GTX3071R GEN II

Download Section

The latest Garrett technologies featuring many advanced features.

File NameLinkView
Configuration GuideDownloadView
File NameLinkView
Compressor MapDownloadView
Exhaust Flow ChartDownloadView
Product PhotoDownloadView
Flange DiagramDownloadView
Speed Sensor Kit Installation InstructionDownloadView

GTX3071R GEN II

Compressor Map & Exhaust Flow Chart

The latest Garrett technologies featuring many advanced features.

Compressor Map

Exhaust Flow Chart

GTX GEN II: The Next Generation in Turbocharging Technology

Garrett Motion is excited to introduce the GTX3071R GEN II Turbocharger. The GTX GEN II is the next evolution of our GTX line with major updates and new technology. Updates include a compressor wheel aero update that gives it the ability to produce up to 20% more horsepower than the previous version.

Redeveloped Compressor Wheels

GTX GEN II compressor wheels were designed using proprietary Garrett Motion computer simulation technology focusing on CFD analysis to optimize the wheel design to reach maximum efficiency and mass flow for each turbocharger.

Each GTX GEN II turbocharger can create more air mass flow, offering enthusiasts a wider range of power output when tuning the vehicle. The 8mm dual ceramic ball bearing cartridge provides optimal turbo response and reliability through its reduction in shaft motion.

Fully-Machined Inlet, Outlet and Shroud

The GEN II GTX Series Turbochargers feature a fully-machined compressor inlet, fully-machined compressor outlet, and fully-machined ported shroud for precise and accurate tolerances.

Redesigned High-Flowing Compressor Housing

We also added a brand-new compressor housing featuring a high-flowing design matched perfectly for the new compressor wheel upgrade. GEN II compressor housings are not interchangeable with GEN I compressor wheels; however, all GEN II turbochargers are outline interchangeable with the equivalent GT and GTX GEN I products making a turbo swap easy to perform using all existing piping.

Fully-Machined Speed Sensor Port

The new compressor housings are equipped with a fully machined speed sensor port that accepts the Garrett Motion speed sensor (Sold separately). This feature allows tuners to understand existing operating conditions, which is important when fine tuning a turbocharger to its most efficient operating conditions. The speed sensor port comes plugged from the factory and can be removed using a 5mm allen key when ready to install a speed sensor kit.

Cross Compatibility Turbo Turbine Housing Kit Platform

All GEN II GTX series turbochargers are compatible with all existing GT and GTX turbine housings kits. GEN II turbochargers are only offered through Garrett Motion authorized distribution centers.
