Turbocharger Data For Obsolete Part Numbers

Turbo Archive Index

Looking for turbocharger data for obsolete part numbers or turbochargers that are not in the performance product section? This is a library of the Garrett performance products from GT, GTX, Gen I, and other turbochargers that are no longer in production.

Family Turbo Name Part Number POWER RANGE DISPLACEMENT COMPRESSOR INDUCER COMPRESSOR EXDUCER TRIM A/R Comp Map TURBINE INDUCER TURBINE EXDUCER TRIM2 A/R2 Turb Map COOLING SYSTEM WASTEGATE ACTUATOR INCLUDED BEARING Comp Wheel Material
GT GT0632SZ 789997-5001S 25 – 80 0.1 – 0.5L 22.6mm 32.0mm 50 0.32 Click 30.0mm 25.5mm 72 0.18 Click Oil Cooled Internal Yes Journal Cast
GT GT1241 756068-5001S 50 – 130 0.4 – 1.2L 28.9mm 32.0mm 50 0.33 Click 35.5mm 30.1mm 72 0.43 Click Oil Cooled Internal Yes Journal Cast
GT GT1544 454083-5002S 25 – 80 0.1 – 0.5L 22.6mm 32.0mm 50 0.32 Click 30.0mm 25.5mm 72 0.35 Click Oil Cooled Internal Yes Journal Cast
GT GT2052 727264-5003S 140 – 230 1.4 – 2.0L 37.6mm 52.2mm 52 0.51 Click 47.0mm 40.0mm 72 0.5 Click Oil Cooled Internal Yes Journal Cast
GT GT2252 452187-5006S 150 – 260 1.7 – 2.5L 40.2mm 52.0mm 60 0.51 Click 50.3mm 42.7mm 72 0.67 Click Oil Cooled Internal Yes Journal Cast
GT GT2554R 836023-5001S 170 – 270 1.4 – 2.2L 42.1mm 54.4mm 60 0.8 Click 53.0mm 41.7mm 62 0.64 Click Oil & Water Cooled Internal Yes Dual Ceramic Ball Bearing Cast
GT GT2560R 836023-5004S 170 – 270 1.4 – 2.2L 42.1mm 54.4mm 60 0.8 Click 53.0mm 41.7mm 62 0.64 Click Oil & Water Cooled Internal Yes Dual Ceramic Ball Bearing Cast
GT GT2860RS 836026-5013S 250 – 360 1.8 – 3.0L 47.2mm 60.1mm 62 0.6 Click 53.9mm 46.9mm 76 0.86 Click Oil & Water Cooled Internal Yes Dual Ceramic Ball Bearing Cast
GT GT2860RS 836026-5014S 250 – 360 1.8 – 3.0L 47.2mm 60.1mm 62 0.6 Click 53.9mm 46.9mm 76 0.64 Click Oil & Water Cooled Internal Yes Dual Ceramic Ball Bearing Cast
GT GT2860RS 836026-5015S 250 – 360 1.8 – 3.0L 47.2mm 60.1mm 62 0.6 Click 53.9mm 46.9mm 76 0.86 Click Oil & Water Cooled Internal Yes Dual Ceramic Ball Bearing Cast
GT GT2860RS 836026-5016S 250 – 360 1.8 – 3.0L 47.2mm 60.1mm 62 0.6 Click 53.9mm 46.9mm 76 N/A Click Oil & Water Cooled Internal Yes Dual Ceramic Ball Bearing Cast
GT GT2860RS 836026-5017S 250 – 360 1.8 – 3.0L 47.2mm 60.1mm 62 0.6 Click 53.9mm 46.9mm 76 N/A Click Oil & Water Cooled Internal Yes Dual Ceramic Ball Bearing Cast
GT GT2871R 836026-5020S 280 – 475 1.8 – 3.0L 53.1mm 71.0mm 56 0.6 Click 53.9mm 46.9mm 76 0.86 Click Oil & Water Cooled Internal Yes Dual Ceramic Ball Bearing Cast
GT GT2871R 836026-5021S 280 – 475 1.8 – 3.0L 53.1mm 71.0mm 56 0.6 Click 53.9mm 46.9mm 76 0.64 Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3071R 836028-5001S 280 – 480 2.0 – 3.5L 53.1mm 71.0mm 56 0.5 Click 60.0mm 55.0mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3071R 836028-5002S 280 – 480 2.0 – 3.5L 53.1mm 71.0mm 56 0.5 Click 60.0mm 55.0mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT2971R 836027-5001S 280 – 480 1.8 – 3.0L 53.1mm 71.0mm 56 0.5 Click 56.5mm 51.8mm 84 0.64 Click Oil & Water Cooled Internal Yes Dual Ceramic Ball Bearing Cast
GT GT2971R 836027-5002S 280 – 480 1.8 – 3.0L 53.1mm 71.0mm 56 0.5 Click 56.5mm 53.6mm 90 0.86 Click Oil & Water Cooled Internal Yes Dual Ceramic Ball Bearing Cast
GT GT3076R 836028-5003S 310 – 525 2.0 – 3.5L 57.0mm 76.2mm 56 0.6 Click 60.0mm 55.0mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3582R 836033-5001S 400 – 600 2.0 – 4.5L 61.4mm 82.0mm 56 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3582R 714568-5002S 400 – 600 2.0 – 4.5L 61.4mm 82.0mm 56 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3582R 714568-5003S 400 – 600 2.0 – 4.5L 61.4mm 82.0mm 56 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3582R 836033-5002S 400 – 675 2.0 – 4.5L 61.4mm 82.0mm 56 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3582R 714568-5008S 400 – 600 2.0 – 4.5L 61.4mm 82.0mm 56 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3582R 714568-5009S 400 – 600 2.0 – 4.5L 61.4mm 82.0mm 56 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3582R 714568-5010S 400 – 600 2.0 – 4.5L 61.4mm 82.0mm 56 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3582R 714568-5010S 400 – 600 2.0 – 4.5L 61.4mm 82.0mm 56 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT3582R 714568-5012S 400 – 600 2.0 – 4.5L 61.4mm 82.0mm 56 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT4202 731376-5002S 600 – 950 2.0 – 8.0L 74.7mm 102.3mm 53 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT4202R 841500-5002S 600 – 950 2.0 – 8.0L 74.7mm 102.3mm 53 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT4202R 774595-5006S 600 – 950 2.0 – 8.0L 74.7mm 102.3mm 53 0.6 Click 82.0mm 75.2mm 85 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT4202R 774595-5007S 600 – 950 2.0 – 8.0L 74.7mm 102.3mm 53 0.6 Click 82.0mm 75.2mm 86 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT4202R 774595-5008S 600 – 950 2.0 – 8.0L 74.7mm 102.3mm 53 0.6 Click 82.0mm 75.2mm 87 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT4294R 841500-5001S 500 – 850 2.0 – 8.0L 70.3mm 94.0mm 56 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT4294R 774595-5002S 500 – 850 2.0 – 8.0L 70.3mm 94.0mm 56 0.6 Click 82.0mm 75.2mm 85 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT4294R 774595-5003S 500 – 850 2.0 – 8.0L 70.3mm 94.0mm 56 0.6 Click 82.0mm 75.2mm 86 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GT GT4294R 774595-5004S 500 – 850 2.0 – 8.0L 70.3mm 94.0mm 56 0.6 Click 82.0mm 75.2mm 87 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Cast
GTW GTW3476R 841691-5001S 450 – 700 2.0 – 4.5L 58.3mm 76.4mm 58 0.7 Click 65.0mm 56.6mm 76 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTW GTW3476 841297-5001S 450 – 700 2.0 – 4.5L 58.3mm 76.4mm 58 0.7 Click 65.0mm 56.6mm 76 N/A Click Oil & Water Cooled External No Journal Bearing Forged Fully Machined
GTW GTW3684R 841691-5002S 425 – 750 2.0 – 5.3L 62.3mm 84.4mm 54 0.7 Click 71.0mm 61.9mm 76 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTW GTW3684 841297-5002S 425 – 750 2.0 – 5.3L 62.3mm 84.4mm 54 0.7 Click 71.0mm 61.9mm 76 N/A Click Oil & Water Cooled External No Journal Bearing Forged Fully Machined
GTW GTW3884R 841691-5003S 450 – 950 2.0 – 6.0L 62.3mm 84.4mm 54 0.7 Click 74.2mm 64.5mm 76 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTW GTW3884 841297-5003S 450 – 950 2.0 – 6.0L 62.3mm 84.4mm 54 0.7 Click 74.2mm 64.5mm 76 N/A Click Oil & Water Cooled External No Journal Bearing Forged Fully Machined
GTW GTW3884R 841691-5004S 450 – 950 2.0 – 6.0L 64.3mm 84.4mm 58 0.7 Click 74.2mm 64.5mm 76 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTW GTW3884 841297-5004S 450 – 950 2.0 – 6.0L 64.3mm 84.4mm 58 0.7 Click 74.2mm 64.5mm 76 N/A Click Oil & Water Cooled External No Journal Bearing Forged Fully Machined
GTW GTW3884R 841691-5005S 450 – 950 2.0 – 6.0L 67.3mm 84.4mm 64 0.7 Click 74.2mm 64.5mm 76 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTW GTW3884 841297-5005S 450 – 950 2.0 – 6.0L 67.3mm 84.4mm 64 0.7 Click 74.2mm 64.5mm 76 N/A Click Oil & Water Cooled External No Journal Bearing Forged Fully Machined
GTX GTX2860R 836040-5002S 220 – 400 1.4 – 2.7L 45.7mm 60.0mm 58 0.6 Click 53.9mm 47.0mm 76 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX2860R Rally 836040-5001S 200 – 300 1.2 – 2.5L 42.0mm 60.0mm 49 0.6 Click 53.9mm 47.0mm 76 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX2867R 836040-5004S 275 – 470 1.8 – 3.0L 49.7mm 67.4mm 55 0.6 Click 53.9mm 47.0mm 76 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX2967R 836041-5001S 275 – 470 1.8 – 3.0L 49.7mm 67.4mm 55 0.6 Click 56.5mm 51.8mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX2971R 836041-5002S 340 – 560 1.8 – 3.0L 54.1mm 71.4mm 58 0.6 Click 56.5mm 51.8mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX2971R 836041-5003S 340 – 560 1.8 – 3.0L 54.1mm 71.4mm 58 0.6 Click 56.5mm 53.6mm 90 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX2976R 836041-5004S 360 – 620 1.8 – 3.0L 58.0mm 76.6mm 58 0.6 Click 56.5mm 53.6mm 90 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3067R 836042-5001S 275 – 470 1.8 – 3.0L 49.7mm 67.4mm 55 0.6 Click 60.0mm 55.0mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3071R 836042-5002S 340 – 560 1.8 – 3.0L 54.1mm 71.4mm 58 0.6 Click 60.0mm 55.0mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3071R 803712-5001S 340 – 560 1.8 – 3.0L 54.1mm 71.4mm 58 0.6 Click 60.0mm 55.0mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3076R 836042-5003S 360 – 620 1.8 – 3.0L 58.0mm 76.6mm 58 0.6 Click 60.0mm 55.0mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3076R 803713-5001S 360 – 620 1.8 – 3.0L 58.0mm 76.6mm 58 0.6 Click 60.0mm 55.0mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3576R 836047-5001S 400 – 620 2.0 – 4.5L 58.0mm 76.6mm 58 0.6 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3576R 803714-5001S 400 – 620 2.0 – 4.5L 58.0mm 76.6mm 58 0.6 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3582R 836047-5002S 440 – 740 2.0 – 4.5L 62.5mm 82.5mm 58 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3582R 803715-5001S 440 – 740 2.0 – 4.5L 62.5mm 82.5mm 58 0.7 Click 68.0mm 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3584RS 846098-5001S 550 – 1000 2.0 – 5.5L 67.0MM 84.0MM 64 0.72 Click 68.0MM 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX3584RS 846098-5002S 550 – 1000 2.0 – 5.5L 67.0MM 84.0MM 64 0.72 Click 68.0MM 62.3mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4088R 825614-5005S 460 – 840 2.0 – 6.0L 65.0mm 88.4mm 54 0.72 Click 77.0mm 68.0mm 78 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4202R 800269-5002S 525 – 1120 2.0 – 7.0L 75.8mm 102.7mm 55 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4202R 800269-5008S 525 – 1120 2.0 – 7.0L 73.8mm 102.7mm 52 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4202R 800269-5007S 525 – 1120 2.0 – 7.0L 71.8mm 102.7mm 49 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4202R 800269-5006S 525 – 1120 2.0 – 7.0L 70.0mm 102.7mm 47 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4294R 800269-5001S 475 – 950 2.0 – 7.0L 70.3mm 94.4mm 56 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4294R 800269-5005S 475 – 950 2.0 – 7.0L 67.8mm 94.4mm 52 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4294R 800269-5004S 475 – 950 2.0 – 7.0L 66.8mm 94.4mm 51 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4294R 800269-5003S 475 – 950 2.0 – 7.0L 64.9mm 94.4mm 48 0.6 Click 82.0mm 75.2mm 84 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4502R 800269-5012S 550 – 1140 2.0 – 8.0L 75.8mm 102.7mm 55 0.6 Click 87.0mm 80.2mm 85 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4502R 800269-5011S 550 – 1140 2.0 – 8.0L 73.8mm 102.7mm 52 0.6 Click 87.0mm 80.2mm 85 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4502R 800269-5010S 550 – 1140 2.0 – 8.0L 71.8mm 102.7mm 49 0.6 Click 87.0mm 80.2mm 85 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4502R 800269-5009S 550 – 1140 2.0 – 8.0L 70.0mm 102.7mm 47 0.6 Click 87.0mm 80.2mm 85 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4508R 800270-5001S 700 – 1250 2.0 – 8.0L 79.8mm 108.4mm 55 0.69 Click 87.0mm 80.2mm 85 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4508R 800270-5002S 700 – 1250 2.0 – 8.0L 77.8mm 108.4mm 52 0.69 Click 87.0mm 80.2mm 85 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4508R 800270-5003S 700 – 1250 2.0 – 8.0L 75.8mm 108.4mm 49 0.69 Click 87.0mm 80.2mm 85 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4594R 800269-5014S 475 – 950 2.0 – 8.0L 70.3mm 94.4mm 56 0.6 Click 87.0mm 80.2mm 85 N/A Click Oil & Water Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4708R 804878-5002S 720 – 1270 2.5 – 10.0L 79.8mm 108.4mm 55 0.69 Click 92.7mm 84.0mm 82 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4708R 804878-5001S 720 – 1270 2.5 – 10.0L 77.8mm 108.4mm 52 0.69 Click 92.7mm 84.0mm 82 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4708R 804878-5003S 720 – 1270 2.5 – 10.0L 75.8mm 108.4mm 49 0.69 Click 92.7mm 84.0mm 82 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4718R 804878-5007S 900 – 1600 2.5 – 10.0L 87.8mm 118.0mm 56 0.69 Click 92.7mm 84mm 82 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4718R 804878-5006S 900 – 1600 2.5 – 10.0L 85.8mm 118.0mm 53 0.69 Click 92.7mm 84mm 82 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4718R 804878-5005S 900 – 1600 2.5 – 10.0L 84.8mm 118.0mm 52 0.69 Click 92.7mm 84mm 82 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX4718R 804878-5004S 900 – 1600 2.5 – 10.0L 81.8mm 118.0mm 48 0.69 Click 92.7mm 84mm 82 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5008R 804878-5020S 720 – 1270 2.5 – 10.0L 79.8mm 108.4mm 55 0.69 Click 98.9mm 91.0mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5008R 804878-5019S 720 – 1270 2.5 – 10.0L 77.8mm 108.4mm 52 0.69 Click 98.9mm 91.0mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5008R 804878-5018S 720 – 1270 2.5 – 10.0L 75.8mm 108.4mm 49 0.69 Click 98.9mm 91.0mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5018R 804878-5024S 900 – 1600 2.8 – 11.0L 87.8mm 118.0mm 56 0.69 Click 98.9mm 91.0mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5018R 804878-5023S 900 – 1600 2.8 – 11.0L 85.8mm 118.0mm 53 0.69 Click 98.9mm 91.0mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5018R 804878-5022S 900 – 1600 2.8 – 11.0L 84.8mm 118.0mm 52 0.69 Click 98.9mm 91.0mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5018R 804878-5021S 900 – 1600 2.8 – 11.0L 81.8mm 118.0mm 48 0.69 Click 98.9mm 91.0mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5518R 812704-5012S 1000 – 1640 3.0 – 12.0L 87.8mm 118.0mm 56 0.81 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5518R 812704-5011S 1000 – 1640 3.0 – 12.0L 85.8mm 118.0mm 53 0.81 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5518R 812704-5010S 1000 – 1640 3.0 – 12.0L 84.8mm 118.0mm 52 0.81 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5518R 812704-5009S 1000 – 1640 3.0 – 12.0L 81.8mm 118.0mm 48 0.81 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5518R 812704-5013S 1000 – 1640 3.0 – 12.0L 87.8mm 118.0mm 56 0.81 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5518R 804878-5011S 1000 – 1600 3.0 – 12.0L 87.8mm 118.0mm 56 0.69 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5518R 804878-5010S 1000 – 1600 3.0 – 12.0L 85.8mm 118.0mm 53 0.69 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5518R 804878-5009S 1000 – 1600 3.0 – 12.0L 84.8mm 118.0mm 52 0.69 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5518R 804878-5008S 1000 – 1600 3.0 – 12.0L 81.8mm 118.0mm 48 0.69 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5518R 804878-5015S 1000 – 1600 3.0 – 12.0L 87.8mm 118.0mm 56 0.69 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5533R 804878-5012S 1000 – 1660 3.0 – 12.0L 91.2mm 133.7mm 47 0.69 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5533R 812704-5001S 1100 – 1780 3.0 – 12.0L 93.8mm 133.7mm 50 0.81 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
GTX GTX5533R 812704-5008S 1150 – 1960 3.0 – 12.0L 98.4mm 133.7mm 54 0.81 Click 111.5mm 102.1mm 84 N/A Click Oil Cooled External No Dual Ceramic Ball Bearing Forged Fully Machined
