Volkswagen 2.0L TDI Plug and Play

Description

Application2.0L TDI BKD/BKP/AZV engines
2003/10-2009/07 – Golf V Mk5 A5 (PQ35) (typ 1K)
2005/08-2011/05 – Jetta A5 (PQ35) (typ 1K)
2003/08-2010/05 – Touran (typ 1T) – [AZV for 136 HP]
2005/09-2010/05 – Passat B6 (typ 1T) – BKP
2004/02-2010/05 – Skoda Octavia Mk2 (typ 1Z) 2nd gen. [AZV for 136HP]
2009/01-2010/03 – Skoda Superb B6 (typ 3T) [BKD EA188]
2005/07-2011/09 – Leon Mk2 (typ 1P)
2004/03-2011/09 – Seat Altea
2004/04-2009/05 – Seat Toledo 3
2003/08-2007/05 – Audi A3 (Typ 8P)
Part Number838946-1 with Gasket kit 828372-1
DescriptionThe Garrett® GTA1749V is a performance upgrade / replacement turbocharger available to the Aftermarket for Volkswagen 2.0L TDI BKD/BKP/AZV engines. The GTA1749V comes equipped with a larger compressor wheel for increased flow and bolts directly to the stock engine manifold flange. The turbo is easy to install and suitable as a performance upgrade or replacement turbocharger. The Garrett VW TDI turbo also promotes a longer turbo and engine life span and increased reliability by lowering exhaust gas temperatures. Includes the Latest Technology Tailored to Your Diesel Performance Needs: – Garrett® patented Variable Nozzle Turbine (VNT™) design – GT wheel aerodynamics Replaces Volkswagen OE Part Numbers: 03G 253 010 J & 03G 253 010 J V100

Volkswagen 2.0L TDI Plug and Play

Compressor Map & Exhaust Flow Chart

Compressor Map

Exhaust Flow Chart

Volkswagen 2.0L TDI Plug and Play

Performance Comparison Sheet

Garrett Turbo Kit
Horsepower190 HP*
* Estimated. Performance results of this product are highly dependent upon your vehicle’s modifications and tuning/calibration. The horsepower numbers represented above are calculated based strictly on choke flow of the compressor map (total turbo capability), which represents the potential flywheel horsepower.

Volkswagen 2.0L TDI Plug and Play

Download Section

ItemLink
FlyerClick to download
Installation InstructionsClick to download
