Volkswagen 1.9L TDI


Application2003.5 – 2006 Volkswagen Beetle TDI 2003.5 – 2006 Volkswagen Golf TDI 2003.5 – 2005 Volkswagen Jetta TDI
Part Number778445-2
DescriptionThe Garrett® GT1749V is the first performance upgrade / replacement turbocharger available to the Aftermarket for Volkswagen 1.9L TDI BEW Engines. The GT1749V comes equipped with a smart actuator, an industry exclusive, and a position sensor, which enables the turbocharger to communicate automatically with the Engine Control Unit (ECU). The kit is easy to install and suitable as a performance upgrade or replacement turbocharger. The Garrett VW TDI Kit also promotes a longer turbo and engine life span and increased reliability by lowering exhaust gas temperatures.

Includes the Latest Technology Tailored to Your Diesel Performance Needs:
– Garrett® patented Variable Nozzle Turbine (VNTTM) design
– GT wheel aerodynamics

Replaces Volkswagen OE Part Numbers: 038 253 019 S & 038 253 014 E Model: KP39 (3K)

Volkswagen 1.9L TDI

Compressor Map & Exhaust Flow Chart

Compressor Map

Volkswagen 1.9L TDI

Performance Comparison Sheet

Garrett Turbo Kit
Horsepower175 HP*
* Estimated. Performance results of this product are highly dependent upon your vehicle’s modifications and tuning/calibration. The horsepower numbers represented above are calculated based strictly on choke flow of the compressor map (total turbo capability), which represents the potential flywheel horsepower.

Volkswagen 1.9L TDI

Download Section

FlyerClick to download
Installation InstructionsClick to download
EGR Tube InstructionsClick to download
